Marathon GT0010A 3 HP 1800 RPM 230/460 Volts General Purpose Motor

Dreisilker SKU: MA-RBC-GT0010A | UPC: 722856068804

(No reviews yet) Write a Review
$1,101.36

Reliable general purpose motor

Top seller, trusted by many customers

Model number: 182TTDBD6026

Product Availability
Typically Ships Within 1 Business Day
Warranty and Returns
Dreisilker products are backed by a 30-day return window and 1-year manufacturer warranty. See our return policy for full details.
Have a question? Ask the motor experts!
Call us at 866-698-3316 | Email us at info@dreisilker.com

Marathon GT0010A Product Description

The Marathon GT0010A general purpose motor is a 3 horsepower 1800RPM 182T frame drip proof 3 phase 230/460 volt 60 hertz motors. This versatile motor is trusted by many customers for different applications and is kept in stock so that our customers will have minimal downtime. The GT0010A replaces the GT0010 motor.

If you are unsure whether or not this motor is the best option for your application, our experts are happy to help you make your decision. Marathon manufactures its motors using the highest standards so that you can be sure you are receiving a great quality product that will last a long while.

Don't miss out on this trusted and versatile motor- purchase the Marathon GT0010A today!

THE DREISILKER PROCESS


Order Today

Simply click the add to cart button and check out securely today to get your order in progress.

Ships Quickly

Fast movers ship same business day when ordered by 2:00 pm CST.

Back to Normal

Get your systems up and running so you can go back to relaxing.

Marathon GT0010A Technical specifications

Brand

Marathon

Catalog Number

GT0010A

Product Category

General Purpose NEMA General Purpose Three Phase Motors > Three Phase ODP Motors

HP

3

Volts

208-230/460

Frequency

60

Amps

8.6-8.0/4.0

RPM (Number of Poles)

4 (1201 RPM to 1800 RPM)

RPM (Nameplate)

1770

Speeds

1

Phase

3

Enclosure Type

Drip Proof

Rotation

Reversible

Mounting Type

Rigid Base

Frame Type

182T

Frame Material

Rolled Steel

Shaft Diameter

1-1/8 (in.)

Shaft Extension

- (in.)

Shaft Type

T

DE Bearing Type

Ball

ODE Bearing Type

Ball

C-Dimension

- (in.)

Electrical Type

Squirrel Cage Inverter Rated

Duty

Continuous

Motor Orientation

Horizontal

Service Factor

1.15

Type of Overload Protector

No

Insulation Class

F

Max Ambient

40°C

UL

Recognized

CE

Y

CSA

Y

IP Code

22

KVA Code

L

DEM Reference

MA#GT0010A
