Marathon GT0016A 7-1/2 HP 1800 RPM 230/460 Volts General Purpose Motor

Dreisilker SKU: MA-RBC-GT0016A | UPC: 722856060150

(No reviews yet) Write a Review
$1,167.27

Reliable general purpose motor

Top seller, trusted by many

Model number: 213TTDBD6026

Product Availability
Typically Ships Within 1 Business Day
Warranty and Returns
Dreisilker products are backed by a 30-day return window and 1-year manufacturer warranty. See our return policy for full details.
Have a question? Ask the motor experts!
Call us at 866-698-3316 | Email us at info@dreisilker.com

Marathon GT0016A Product Description

If you're looking for a versatile and reliable general purpose motor, the Marathon GT0016A is a great option. This 7-1/2 HP 1800 RPM 230/460 Volts Motor is trusted by many customers for different applications, so we keep it in stock to minimize downtime. Marathon only manufactures its motors using the highest standards, so you can be sure you're receiving a great quality product that will last. The Marathon GT0016A also replaces the GT0016 motor. If you're unsure whether or not this motor is the best option for your application, reach out to the motor experts and we are happy to help you make your decision.

THE DREISILKER PROCESS


Order Today

Simply click the add to cart button and check out securely today to get your order in progress.

Ships Quickly

Fast movers ship same business day when ordered by 2:00 pm CST.

Back to Normal

Get your systems up and running so you can go back to relaxing.

Marathon GT0016A Technical specifications

Brand

Marathon

Catalog Number

GT0016A

Product Category

General Purpose NEMA General Purpose Three Phase Motors > Three Phase ODP Motors

HP

7-1/2

Volts

208-230/460

Frequency

60

Amps

21.2-19.8/9.9

RPM (Number of Poles)

4 (1201 RPM to 1800 RPM)

RPM (Nameplate)

1766

Speeds

1

Phase

3

Enclosure Type

Drip Proof

Rotation

Reversible

Mounting Type

Rigid Base

Frame Type

213T

Frame Material

Rolled Steel

Shaft Diameter

1-3/8 (in.)

Shaft Extension

3.38 (in.)

Shaft Type

T

DE Bearing Type

Ball

ODE Bearing Type

Ball

C-Dimension

17.52 (in.)

Electrical Type

Squirrel Cage Inverter Rated

Duty

Continuous

Motor Orientation

Horizontal

Service Factor

1.15

Type of Overload Protector

No

Insulation Class

F

Max Ambient

40°C

UL

Recognized

CE

Y

CSA

Y

IP Code

22

KVA Code

H

DEM Reference

MA#GT0016A
