Brand
Morrill Motors
Catalog Number
5R031
Product Category
HVAC/R Motors > Unit Bearing Motors
Watts
16
Volts
115
Frequency
60
Amps
0.4
RPM (Number of Poles)
4 (1201 RPM to 1800 RPM)
RPM (Nameplate)
1550
Number of speeds
-
Number of Phases
1
Enclosure Type
Totally Enclosed Air Over
Rotation
Clockwise Opposite Shaft End
Mounting Type
2 BOSS/OSE 5 HOLES
Frame Type
Unit Bearing
Frame Material
Aluminum
Shaft Diameter (In.)
0.250
Shaft Extension (In.)
0.33
Shaft Type
1/4-20 THREAD
DE Bearing Type
Ball
ODE Bearing Type
Ball
C-Dimension (In.)
3.54
Electrical Type
Electronically Commutated Motor
Duty
Continuous Air Over
Motor Orientation
Any
Service Factor
-
Type of Overload Protector
Electronically Protected
Insulation Class
B
Max Ambient
55°C
UL
Yes
CE
N
CSA
Y
IP Code
-
KVA Code
-
DEM Reference
NOHP
