Inventory and Shipping Information
Brand
Fasco
Catalog Number
D1086
Product Category
HVAC/R Motors > HVAC/R OEM Replacement Motors
HP
1/12
Volts
277
Frequency
60
Amps
0.6
RPM (Number of Poles)
4 (1201 RPM to 1800 RPM)
RPM (Nameplate)
1625
Speeds
2
Phase
1
Enclosure Type
Open Air Over
Rotation
Counterclockwise Shaft End
Mounting Type
Resilient Rings
Frame Type
42
Frame Material
Na
Shaft Diameter
1/2 (in.)
Shaft Extension
6.5 (in.)
Shaft Type
Flat
DE Bearing Type
Sleeve
ODE Bearing Type
Sleeve
C-Dimension
16.28 (in.)
Electrical Type
Permanent Split Capacitor
Duty
Continuous
Motor Orientation
-
Service Factor
1
Type of Overload Protector
Automatic
Insulation Class
B
Max Ambient
40°C
UL
Recognized
CE
N
CSA
Y
IP Code
-
KVA Code
-
DEM Reference
FA#D1086
