Product Description
Technical specifications
Brand
Fasco
Catalog Number
D429
Product Category
HVAC/R Motors > Refrigeration Motors
Watts
9
Volts
115
Frequency
50
Amps
0.70
RPM (Number of Poles)
4 (1201 RPM to 1800 RPM)
RPM (Nameplate)
1550
Number of speeds
1
Number of Phases
1
Enclosure Type
Totally Enclosed Air Over
Rotation
Counterclockwise Shaft End
Mounting Type
Extended Studs
Frame Type
3.3
Frame Material
Steel
Shaft Diameter (In.)
0.313
Shaft Extension (In.)
1.2
Shaft Type
Threaded
DE Bearing Type
Sleeve
ODE Bearing Type
Sleeve
C-Dimension (In.)
-
Electrical Type
Shaded Pole
Duty
Continuous Air Over
Motor Orientation
-
Service Factor
1
Type of Overload Protector
Thermally Protected
Insulation Class
B
Max Ambient
40°C
UL
Recognized
CE
N
CSA
Y
IP Code
-
KVA Code
-
DEM Reference
FA#D429
