Fasco D457 HP 1/15 RPM 3000 Volts 115/230 Amps 2-1 Rotation CCW Shaft Diameter 1/4
Product Description
Fasco D457 HP 1/15 RPM 3000 Volts 115/230 Amps 2-1 Rotation CCW Shaft Diameter 1/4
Technical specifications
Brand
Fasco
Catalog Number
D457
Product Category
HVAC/R Motors > HVAC/R OEM Replacement Motors
HP
0.07
Volts
115/230
Frequency
60
Amps
2.0/1.0
RPM (Number of Poles)
2 (1801 RPM to 3600 RPM)
RPM (Nameplate)
3000
Number of speeds
1
Number of Phases
1
Enclosure Type
Open Air Over
Rotation
Counterclockwise Shaft End
Mounting Type
Extended Studs
Frame Type
3.3
Frame Material
Steel
Shaft Diameter (In.)
0.250
Shaft Extension (In.)
2.75
Shaft Type
Flat
DE Bearing Type
Ball
ODE Bearing Type
Ball
C-Dimension (In.)
9.41
Electrical Type
Shaded Pole
Duty
Air Over
Motor Orientation
-
Service Factor
1
Type of Overload Protector
Thermally Protected
Insulation Class
B
Max Ambient
40°C
UL
Recognized
CE
N
CSA
Y
IP Code
-
KVA Code
-
DEM Reference
FA#D457
